Magnetic Stripe BV/TV Series on PVC Card

Short Description:

Lucky “BV” Series Magnetic Stripe is heat transfer (cold peel) magnetic foil for application on plastic card.

Lucky “TV” Series Magnetic Stripe is total lamination magnetic stripe for application on PVC card.

Send email to us

Product Detail

Product Tags

Heat Transfer (cold peel) Magnetic Stripe for application on Plastic card–“BV” Series

Lucky “BV” Series Magnetic Stripe is heat transfer (cold peel) magnetic foil for application on plastic card.
This kind of magnetic stripe is applied on plastic substrate (for example Overlay) to produce plastic card on Tape Layer Machine. During the processing, magnetic stripe is stamped onto PVC overlay by heated roller, and then the PET carrier of magnetic foil is peeled off and discarded once the adhesive cooled.

Product Code	Coercivity (Oe)	Color	Adhesive Type	Application Method	Signal Amplitude	Applications
LK360BV11	360	Black	PVC	Heat Transfer	80~130%	Plastic Cards, Bank Cards
LK360BV22	360	Dark Brown	PVC	Heat Transfer	80~130%	Plastic Cards, Bank Cards
LK2750BV11	2750	Black	PVC	Heat Transfer	80~120%	Plastic Cards, Bank Cards
LK2750BV31	2750	Gold	PVC	Heat Transfer	80~120%	Plastic Cards, Bank Cards
LK2750BV41	2750	Silver	PVC	Heat Transfer	80~120%	Plastic Cards, Bank Cards
LK2750BV51	2750	Red	PVC	Heat Transfer	80~120%	Plastic Cards, Bank Cards
LK2750BV61	2750	Green	PVC	Heat Transfer	80~120%	Plastic Cards, Bank Cards
LK2750BV71	2750	Blue	PVC	Heat Transfer	80~120%	Plastic Cards, Bank Cards
LK4000BV11	4000	Black	PVC	Heat Transfer	80~120%	Plastic Cards, Bank Cards
LK2750BV32	2750	Both Sides Gold	PVC	Heat Transfer	80~120%	Plastic Cards, Bank Cards
LK2750BV42	2750	Both Sides Silver	PVC	Heat Transfer	80~120%	Plastic Cards, Bank Cards

Total Lamination Magnetic Stripe for application on PVC Card – “TV” Series

Lucky “TV” Series Magnetic Stripe is total lamination magnetic stripe for application on PVC card. This kind tape is not need to peel off the PET carrier, and is laminated on the PVC cards with both Magnetic Layer and Base Film. It is suitable for the minimum quantity production using laminator machine.

Product Code	Coercivity (Oe)	Color	Adhesive Type	Application Method	Signal Amplitude	Applications
LK360TV1	360	Black	PVC	Total Lamination	80~130%	Plastic Cards, Bank Cards
LK360TV2	360	Brown	PVC	Total Lamination	80~130%	Plastic Cards, Bank Cards
LK2750TV1	2750	Black	PVC	Total Lamination	80~130%	Plastic Cards, Bank Cards
LK2750TV3	2750	Gold	PVC	Total Lamination	80~130%	Plastic Cards, Bank Cards
LK2750TV4	2750	Silver	PVC	Total Lamination	80~130%	Plastic Cards, Bank Cards
LK4000TV1	4000	Black	PVC	Total Lamination	80~130%	Plastic Cards, Bank Cards
